DEVMO 2PCS Heat Bed Mosfet,3D Printer Heat Bed Power Module 3D Printer Board Expansion Board 25A MOS Tube High Current Load Module

Detalles del producto
Disponibilidad:
En stock
Peso con empaque:
0.15 kg
Devolución:
Condición
Nuevo
Producto de:
Amazon
Viaja desde
USA

Sobre este producto
  • Product Description: Heated bed power module Based on powerful MOSFET HA210NO6 Size: 60*50mm Mounting holes: 3.2mm diameter, for M3 screws. Distance betweeen holes: 54*43mm Very powerful MOSFET to withstand higher current than normal RAMPS or other 3D Printer controller can handle Voltage: 12V-24V Maximum current with active cooling: 210A This module is based on power MOSFET and will allow PID control of the heated bed (DC-DC Relays usually do not allow this) Under the premise of normal cooling, it work stable under I(Max)=25A, the current must not exceed 25A while the process workingPackage Includes: 1 x Heated Bed Power Module 1 x Connection cable for input signal
AR$50.854
55% OFF
AR$23.114

IMPORT EASILY

By purchasing this product you can deduct VAT with your RUT number

AR$50.854
55% OFF
AR$23.114

10% OFF con cupon ANIVERSARIO10

Pagá fácil y rápido con Mercado Pago o MODO

Llega en 8 a 12 días hábiles
con envío
Tienes garantía de entrega
Este producto viaja de USA a tus manos en

Conoce más detalles

WELL MADE- New material with superior quality stainless, High-grade Aluminum block for best connectivity and long life. HIGH TRANSMISSION - With this addon module to your 3D printer motherboard you can lead the maximum current up to 25A. MULTIFUNCTION - Completely solve the hot bed power is too large and load current problems,and can well protect the connectors on the controller board from overheating. MEET YOUR NEEDS -Widely used for common 3D printer models,extruder and other open 3D printer motherboards.such as Anet A8, etc. WARNING - For use on some devices (for example,Anet A8),you need to make sure the power supply is set to 110 volts instead of the default 220 volts.If the voltage is too high, the product will get super hot, even charred!! Don't touch it lightly.
