APIELE 16mm Latching Push Button Switch 0.63" 12V Power Symbol Ring Led Car Metal with Socket Plug 1NO1NC SPDT ON/Off (Blue/Black Shell)
Color:
Blue/ Black Shell
En stock
0.15 kg
Sí
Nuevo
Amazon
USA
- Latching switch The Latching switch will remain on once it ispressed and stay on until it is pressed again. Specification: - Switch Rating: 5A/250VAC - Operation Temperature: -20℃~ +55℃ - Mechanical life: 1,000,000 cycles - Electrical life: 200,000 cycles - Panel thickness: 1 - 10mm - Protection level: IP65, IK10 - Mounting Cut Hole: 16mm - Head Diameter: 18.8mm - Operation Type: Latching - Switch Contact: 1NO 1NC - LED Rating: 15mA, AC/DC 12V - LED Pattern: Power Indicator - Contact Material: Silver alloy - Button Material: Aluminum Alloy Note: - The switch come with a rubber O-ring whichmakes it splash resistant but it can NOT be submerged underwater. Packing Include: 1 x pushbutton switch 1 x pigtail socket 1 x Wiring diagram
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
GET NEW ONE IF NOT MAN MADE BROKEN IN 3 YEARS SINCE YOU PURCHASE THE SWITCH. Brand New Black AluminiumPower Symbol Pushbutton Switch; LED voltage: 12V only, Hole size required: 0.63''/16mm Latching switch: Push it, ON; Push it again, OFF. Contact Configuration: 1NO1NC Electrical life: 200 thousand times. Mechanical life: 1,000,000 cycles Latching switch: Push it, ON; Push it again, OFF. Contact Configuration: 1NO1NC
